Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Montana, 2003 Oldsmobile Silhouette, and 2003 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the rear bumper fascia. Refer to FASCIA REPLACEMENT - REAR BUMPER (PONTIAC)  in Bumpers.
  2. Remove the rear accessory panel. Refer to ACCESSORY PANEL REPLACEMENT - REAR  in Interior Trim.
  3. Use a small, flat-bladed tool in order to push on the retainers from the inside of the quarter panel.
  4. Remove the pressure relief valve from the body.
    Fig 1: Removing Pressure Relief Valve From Body
    G01533435Courtesy of GENERAL MOTORS CORP.
