Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Montana, 2003 Oldsmobile Silhouette, and 2003 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the push-pin retainers from the rear seat back finish panel with a flat bladed tool.
  2. Remove the outer portion of the push-pin retainer from the seat back finish panel.
  3. Remove the seat back finish panel from the seat back.
    Fig 1: Removing Seat Back Finish Panel From Seat Back
    G01532084Courtesy of GENERAL MOTORS CORP.
