Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Montana, 2003 Oldsmobile Silhouette, and 2003 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the ashtray to the IP accessory trim plate.
  2. Connect the electrical connectors.
  3. Press the ashtray into the IP accessory trim plate.
  4. Install the locking metal housing center ashtray retaining tab to the accessory trim plate.
  5. Install the IP accessory trim plate. Refer to TRIM PLATE REPLACEMENT - INSTRUMENT PANEL (I/P) ACCESSORY  .
    Fig 1: Installing Ashtray From Instrument Panel Accessory Trim Plate
    G01534532Courtesy of GENERAL MOTORS CORP.
