Diagnostic Aids

WARNING: This page is about a different car, the 2003 Pontiac Montana, 2003 Oldsmobile Silhouette, and 2003 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.

The IPC will store the code as current only as long as the failure exists. An intermittent failure will be stored as a history DTC B2823.
If DTC B2823 is set only in history, press and release the trip reset switch several times in order to verify the customer concern.

Fig 1: Diagnostic Chart - Diagnostic System Check Chart - DTC B2823 or B3574

Courtesy of GENERAL MOTORS CORP.
