Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Montana, 2003 Oldsmobile Silhouette, and 2003 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the automatic level control air compressor. Refer to AIR COMPRESSOR REPLACEMENT   .
  2. Remove the air compressor shield.
    Fig 1: Removing Air Compressor Shield
    G01483372Courtesy of GENERAL MOTORS CORP.
