Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the liftgate trim panel. Refer to TRIM PANEL REPLACEMENT -- LIFT GATE in Body Rear End.
  2. Disconnect the hose from the liftgate harness.
  3. Disconnect the hose from the liftgate inner panel.
  4. Remove the 2 clips that secure the hose to the liftgate.
    Fig 1: Disconnecting Hose From Liftgate Inner Panel
    G01476401Courtesy of GENERAL MOTORS CORP.
