Installation Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the rear floor air outlets to the center floor air outlet.
  2. Install the passenger seat wiring harness to the right rear floor air outlet.
  3. Install the carpet.
  4. Install the passenger and driver side kick panels.
  5. Install the passenger and driver door sill plates. Refer to DOOR SILL PLATE REPLACEMENT in Interior Trim.
  6. Install the center floor console. Refer to CONSOLE REPLACEMENT -- FRONT FLOOR (FULL LENGTH (AUTO TRANS)) or CONSOLE REPLACEMENT -- FRONT FLOOR (FULL LENGTH ENVOY)) or CONSOLE REPLACEMENT -- FRONT FLOOR (NON-FULL LENGTH) or CONSOLE REPLACEMENT -- FRONT FLOOR (FULL LENGTH (MANUAL TRANS)) in Instrument Panel, Gages and Console.
  7. Install the passenger front seat and the driver front seat. Refer to SEAT REPLACEMENT -- BUCKET in Seats.
    Fig 1: Center Floor Console
    G01466985Courtesy of GENERAL MOTORS CORP.
