Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the A/C low pressure switch electrical connector.
  2. Remove the A/C low pressure switch (5) from the accumulator.
    Fig 1: A/C Low Pressure Switch Electrical Connector & A/C Low Pressure Switch
    G01466918Courtesy of GENERAL MOTORS CORP.
