Test Description

WARNING: This page is about a different car, the 2003 Pontiac Aztek and 2003 Buick Rendezvous. However, it is still accessible from the selected car via links, so may be relevant.

The steps below refer to the test steps in the diagnostic table

  1. 3. Inspect the engine for mechanical failure, or the binding of driven components including driveline related components.
Fig 1: Starter Solenoid Clicks; Engine Does Not Crank Diagnosis
G01501051Courtesy of GENERAL MOTORS CORP.
