Diagnostic Aids

WARNING: This page is about a different car, the 2002 Oldsmobile Aurora and 2001 Oldsmobile Aurora. However, it is still accessible from the selected car via links, so may be relevant.

Refer to TESTING FOR INTERMITTENT AND POOR CONNECTIONS and TESTING FOR ELECTRICAL INTERMITTENTS .

Fig 1: DTC P1626
G01801338Courtesy of GENERAL MOTORS CORP.
