Installation Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Intrigue. However, it is still accessible from the selected car via links, so may be relevant.
  1. Align the spring clips to slots in rear compartment.
  2. Press down on the rear compartment sill plate. Apply even pressure until fully seated.
  3. Close the rear compartment.
    Fig 1: Installing Rear Compartment
    G01832157Courtesy of GENERAL MOTORS CORP.
