Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Intrigue. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open the rear compartment.
  2. Place protective coverings over the adjacent body panels.
  3. Use a grease pencil to mark the hinge to the rear compartment lid for proper location at installation.
  4. Remove the wiring harness. Refer to Wiring Harness Replacement - Rear Compartment Lid
  5. Remove the lock cylinder. Refer to Lock Cylinder Replacement - Rear Compartment Lid
  6. Remove the rear compartment lid black rubber bumpers.
    Fig 1: Removing Rear Compartment Lid Black Rubber Bumpers
    G01832187Courtesy of GENERAL MOTORS CORP.
  7. Remove the rear compartment lid latch. Refer to Latch Replacement - Rear Compartment Lid
  8. Remove the rear compartment lid trim. Refer to Compartment Lid Trim Replacement - Rear
  9. With an assistant, remove the rear compartment lid hinges to rear compartment lid bolts.
  10. With an assistant, remove the rear compartment lid from the vehicle.
