Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Intrigue. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the rear window trim panel. Refer to TRIM PANEL REPLACEMENT - REAR WINDOW SHELF
  2. Remove the rear speaker grille nuts from the bottom of the rear speaker grille.
  3. Remove the rear speaker grille from the rear window trim panel.
    Fig 1: Remove Rear Window Trim Panel, Speaker Grille & Nuts
    G01830777Courtesy of GENERAL MOTORS CORP.
