Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Intrigue. However, it is still accessible from the selected car via links, so may be relevant.
  1. Lower the rear door window to the full open position.
  2. Remove the rear door outer belt sealing strip to rear door screw.
  3. Lift up on the rear door outer belt sealing strip to remove from the rear door pinch-weld flange.
    Fig 1: Rear Door Outer Belt Sealing Strip To Rear Door Screws
    G01831981Courtesy of GENERAL MOTORS CORP.
