Up/Down or In/Out Adjustment
WARNING: This page is about a different car, the 2002 Oldsmobile Intrigue. However, it is still accessible from the selected car via links, so may be relevant.
Important: Do not completely remove the hinge to door and hinge to body bolts.
- Loosen the hinge to door bolts (2).
- Adjust the door up or down and in or out as required.NOTE: Refer to FASTENER NOTICE .
- Tighten the hinge to door bolts (2).
Tighten
Tighten the bolts to 33 N.m (24 lb ft).
