Diagnostic Trouble Code (DTC) List
WARNING: This page is about a different car, the 2002 Oldsmobile Intrigue. However, it is still accessible from the selected car via links, so may be relevant.
DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION
| DTC | Description |
|---|---|
| C0035 | LF Wheel Speed Circuit Malfunction |
| C0040 | RF Wheel Speed Circuit Malfunction |
| C0041 | RF Wheel Speed Sensor Circuit Range/Performance (EBCM) |
| C0045 | LR Wheel Speed Circuit Malfunction |
| C0046 | LR Wheel Speed Sensor Circuit Range/Performance (EBCM) |
| C0050 | RR Wheel Speed Circuit Malfunction |
| C0051 | LF Wheel Speed Sensor Circuit Range/Performance (EBCM) |
| C0060 | LF ABS Solenoid #1 Circuit Malfunction |
| C0065 | LF ABS Solenoid #2 Circuit Malfunction |
| C0070 | RF ABS Solenoid #1 Circuit Malfunction |
| C0075 | RF ABS Solenoid #2 Circuit Malfunction |
| C0080 | LR ABS Solenoid #1 Circuit Malfunction |
| C0085 | LR ABS Solenoid #2 Circuit Malfunction |
| C0060 | LF ABS Solenoid #1 Circuit Malfunction |
| C0065 | LF ABS Solenoid #2 Circuit Malfunction |
| C0070 | RF ABS Solenoid #1 Circuit Malfunction |
| C0075 | RF ABS Solenoid #2 Circuit Malfunction |
| C0080 | LR ABS Solenoid #1 Circuit Malfunction |
| C0085 | LR ABS Solenoid #2 Circuit Malfunction |
| C0090 | RR ABS Solenoid #1 Circuit Malfunction |
| C0095 | RR ABS Solenoid #2 Circuit Malfunction |
| C0110 | Pump Motor Circuit Malfunction |
| C0121 | Valve Relay Circuit Malfunction |
| C0131 | ABS/TCS System Pressure Circuit Malfunction |
| C0132 | ABS/TCS System Pressure Circuit Range Performance |
| C0141 | Left TCS Solenoid #1 Circuit Malfunction |
| C0146 | Left TCS Solenoid #2 Circuit Malfunction |
| C0151 | Right TCS Solenoid #1 Circuit Malfunction |
| C0156 | Right TCS Solenoid #2 Circuit Malfunction |
| C0161 | ABS/TCS Brake Switch Circuit Malfunction |
| C0186 | Lateral Accelerometer Circuit Malfunction |
| C0187 | Lateral Accelerometer Circuit Range Performance |
| C0196 | Yaw Rate Circuit Malfunction |
| C0197 | Yaw Rate Circuit Range Performance |
| C0235 | Rear Wheel Speed Signal Circuit Open |
| C0236 | Rear Wheel Speed Signal Circuit Missing |
| C0237 | Rear Wheel Speed Signal Erratic |
| C0240 | PCM Traction Control Not Allowed |
| C0241 | PCM Indicated Requested Torque Malfunction |
| C0244 | PWM Delivered Torque Malfunction |
| C0245 | Wheel Speed Sensor Frequency Error |
| C0252 | EBCM Control Valve Circuit |
| C0253 | EBCM Control Valve Circuit |
| C0550 | ECU Malfunction - internal write/checksum malfunction |
| C0710 | Steering Position Signal Malfunction |
| C0870 | Device Voltage Reference Output 1 Circuit Malfunction |
| C0875 | Device Voltage Reference Input 2 Circuit Malfunction |
| C0896 | Device Voltage Range Performance |
| P1504 | Vehicle Speed Output Circuit |
| P1571 | TCS PWM Circuit No Frequency |
| P1689 | TCS Delivered Torque Control Circuit |
| U1650 | Loss of Class 2 serial data communications |
| U1651 | Loss of Class 2 serial data communications |
