Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Intrigue, 2001 Oldsmobile Intrigue, and 2000 Oldsmobile Intrigue. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the radiator. Refer to Radiator Replacement .
  2. Remove the radiator side baffles.
  3. Clean the radiator side baffles mounting surface.
    Fig 1: Remove Radiator Side Baffles
    G01758071Courtesy of GENERAL MOTORS CORP.
