Removal & Installation
WARNING: This page is about a different car, the 2002 Oldsmobile Aurora. However, it is still accessible from the selected car via links, so may be relevant.
Remove Right Temperature switch plate by prying up on forward edge, using a tool with a flat blade. Disconnect harness connector. Remove Passenger-Side Temperature Control Switch assembly from switch plate. See Fig 1. To install, reverse removal procedure.
