Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Sunfire and 2003 Chevrolet Cavalier. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front seat shoulder belt guide cover.
  2. Remove the front seat shoulder belt guide bolt.
  3. Pull the center pillar upper trim panel (1) outward at the roof in order to disengage the clips.
  4. Remove the center pillar trim panel from the vehicle.
    Fig 1: Removing Center Pillar Trim Panel
    G01559951Courtesy of GENERAL MOTORS CORP.
