Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Sunfire and 2003 Chevrolet Cavalier. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front bucket seat back. Refer to SEAT BACK REPLACEMENT - FRONT  .
  2. Remove the front seat head restraint. Refer to HEAD RESTRAINT REPLACEMENT - FRONT SEAT  .
  3. Disconnect the J-hook retainer (1).
  4. Remove the release lever knob (5) from the recliner (8), if equipped.
  5. Pull the bottom of the seat back cover assembly (2) up and over the frame (11).
    Fig 1: Disconnecting J-Hook Retainer (Front Without AJ7)
    G01559883Courtesy of GENERAL MOTORS CORP.
