Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Sunfire and 2003 Chevrolet Cavalier. However, it is still accessible from the selected car via links, so may be relevant.
  1. Use a flat bladed tool to lift the roof weld joint reveal molding (1) upward.
  2. Remove the roof weld joint molding from the roof.
  3. Clean the weld joint with a 3M™ Scotch Brite adhesive remover disk P/N 07501 or equivalent.
    Fig 1: Lifting Roof Weld Joint Reveal Molding Upward Using Flat Bladed Tool
    G01559428Courtesy of GENERAL MOTORS CORP.
