Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Sunfire and 2003 Chevrolet Cavalier. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the hazard and turn signal flasher module (1) from the brake pedal bracket (3).
  2. Disconnect the electrical connector (2) from the flasher module (1).
  3. Remove the flasher module (1) from the vehicle, if required.
    Fig 1: Disconnecting Electrical Connector From Flasher Module
    G01558857Courtesy of GENERAL MOTORS CORP.
