Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Sunfire and 2003 Chevrolet Cavalier. However, it is still accessible from the selected car via links, so may be relevant.
  1. Connect the electrical connector (2) to the flasher module (1).
  2. Install the flasher module (1) to the brake pedal bracket (3).
  3. Press the flasher module (1) until the rosebud retainer is secured to the brake pedal bracket (3).
    Fig 1: Connecting Electrical Connector To Flasher Module
    G01558858Courtesy of GENERAL MOTORS CORP.
