Removal Procedure

WARNING: This page is about a different car, the 2002 Pontiac Sunfire and 2002 Chevrolet Cavalier. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise the vehicle on a hoist.
  2. Remove the tire and wheel assemblies.
  3. Remove the drive axle nut.
  4. Remove the brake rotor.
  5. Remove the mounting bolts (1) from the hub and bearing assembly (3).
    Fig 1: Hub And Bearing Assembly
    G01583090Courtesy of GENERAL MOTORS CORP.
  6. Remove the hub and bearing assembly (1) from the steering knuckle (2) and drive axle shaft.
