Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Sunfire and 2003 Chevrolet Cavalier. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise and suitably support the vehicle.
  2. Remove the front wheel and tire assemblies.
  3. Remove the wheel driveshaft.
  4. Use the SA9133T in order to remove the seal.
  5. Inspect the seal bore for nicks or for burrs. Clean the bore with a fine grade sandpaper, if necessary.
    Fig 1: Removing Axle Shaft Oil Seal
    G01558190Courtesy of GENERAL MOTORS CORP.
