Engine Lubrication System: Notes
WARNING: This page is about a different variant/trim than selected.
A gerotor-type oil pump provides pressurized lubrication through full-flow oil filter. Oil pump is bolted to front of cylinder block, behind front cover, and is driven directly by crankshaft. See Fig 1 .
