Removal Procedure

WARNING: This page is about a different car, the 2002 Pontiac Firebird and 2002 Chevrolet Camaro. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise and suitably support the vehicle.
  2. Remove the engine mount heat shield nuts.
  3. Remove the engine mount heat shield.
    Fig 1: Removing Engine Mount Heat Shield
    G01731971Courtesy of GENERAL MOTORS CORP.
