System Tests: Notes
CAUTION:
Static electricity can destroy integrated circuits in instrument cluster and VSS calibrator. Before servicing these components, ground yourself and work area to discharge static electricity.
NOTE:
Unless otherwise specified, make all voltage and resistance measurements with a Digital Volt-Ohmmeter (DVOM) having an input impedance of 10 megohms or greater.
NOTE:
To locate components, see COMPONENT LOCATIONS
. To identify connectors, see CONNECTOR IDENTIFICATION
. See Figure
through Figure
.
