Installation Procedure

1. Install the belt (1).

NOTICE: Refer to Fastener Notice in Service Precautions.

2. Install the bolt/screw (3) that attaches the belt (1) to the floor pan.
Tighten
Tighten the bolt/screw (3) to 42 N.m (31 lb. ft).
3. Connect the plug (2) to the bolt/screw (3).
4. Install the driver seat belt warming electrical connector.
5. Install the front seat. Refer to Seats in Body and Accessories.
