Manual Transmission/Transaxle: Description and Operation

The Getrag 284 five speed manual transaxle, is a constant mesh design transaxle. All forward and reverse gears and the differential output are combined in the assembly. Selection and shifting is accomplished by a combination of synchronizers with blocker rings controlled by sliding rail shift forks.
