Special Tools

WARNING: This page is about a different car, the 2023 GMC Sierra 3500 HD and 2023 GMC Sierra 2500 HD. However, it is still accessible from the selected car via links, so may be relevant.

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS COMPANY	DT-8092 GE-8092 J-8092 Driver Handle
Courtesy of GENERAL MOTORS COMPANY	DT-03289-20 J-3289-20 Holding Fixture (Base)
Courtesy of GENERAL MOTORS COMPANY	DT-21366 J-21366 Converter Holding Strap
Courtesy of GENERAL MOTORS COMPANY	DT-22912-B J-22912-B Bearing Remover
Courtesy of GENERAL MOTORS COMPANY	DT-26941 J-26941 Bushing and Bearing Remover
Courtesy of GENERAL MOTORS COMPANY	DT-36850 Transjel Lubricant
Courtesy of GENERAL MOTORS COMPANY	DT-45000 J-45000 Seal Remover
Courtesy of GENERAL MOTORS COMPANY	DT-45096 J-45096 Transmission Oil Cooling System Flush and Flow Test Tool
Courtesy of GENERAL MOTORS COMPANY	DT-45096-40 J-45096-40 Transflow Oil Fill Adapter
Courtesy of GENERAL MOTORS COMPANY	DT-45096-85 J-45096-85 Transmission Flusher Adapters
Courtesy of GENERAL MOTORS COMPANY	DT-47800 Thrust Washer Selection Gauge Kit
Courtesy of GENERAL MOTORS COMPANY	DT-48212 Input Shaft Pilot Bearing Installer
Courtesy of GENERAL MOTORS COMPANY	DT-48307 Holding Fixture
Courtesy of GENERAL MOTORS COMPANY	DT-48307-10 Fixture Adapter
Courtesy of GENERAL MOTORS COMPANY	DT-50315 Hardware Kit
Courtesy of GENERAL MOTORS COMPANY	DT-50903 Clutch Travel Load Gauge
Courtesy of GENERAL MOTORS COMPANY	DT-50921 Output Carrier Lifter
Courtesy of GENERAL MOTORS COMPANY	DT-51672 Seal Installer
Courtesy of GENERAL MOTORS COMPANY	DT-51892 Bridge Kit
Courtesy of GENERAL MOTORS COMPANY	DT-52081 End Play Gauge Plate
Courtesy of GENERAL MOTORS COMPANY	DT-52089 Wiring Harness Connector Remover
Courtesy of GENERAL MOTORS COMPANY	DT-52090 Rotating Shell Assembly Lift Adapter Bar
Courtesy of GENERAL MOTORS COMPANY	DT-52322 Seal Remover
Courtesy of GENERAL MOTORS COMPANY	DT-52659 Torque Converter Lift Bracket
Courtesy of GENERAL MOTORS COMPANY	DT-52673 Oil Seal Can Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52674 Stator Shaft Seal Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52675 Cooler Line Seal Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52676 Turbine Shaft Seal Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52677 Turbine Shaft Seal Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52678 Turbine Shaft Rear Seal Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52679 Output Shaft Seal Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52680 Turbine Shaft Upper Seal Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52681 Clutch Spring Compressor
Courtesy of GENERAL MOTORS COMPANY	DT-52682 Clutch Spring Compressor
Courtesy of GENERAL MOTORS COMPANY	DT-52684 Stator Shaft Bearing Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52685 Torque Converter/Extension Housing Seal Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52688 Power Take-Off Front Seal Installer
Courtesy of GENERAL MOTORS COMPANY	DT-52700 Clutch Pack Rotation Fixture
Courtesy of GENERAL MOTORS COMPANY	EN-51146 Injector Remover/Installer
Courtesy of GENERAL MOTORS COMPANY	EN-51187 Injector Puller
Courtesy of GENERAL MOTORS COMPANY	EN-52451 Injector Puller
Courtesy of GENERAL MOTORS COMPANY	GE-26900-13 J-26900-13 Magnetic Base
Courtesy of GENERAL MOTORS COMPANY	GE-8433-1 Puller Bar
Courtesy of GENERAL MOTORS COMPANY	J-22828 Input and Countershaft Race Installer
Courtesy of GENERAL MOTORS COMPANY	J-24420-C Crankshaft Balancer Puller
Courtesy of GENERAL MOTORS COMPANY	J-43074 Clutch Spring Compressor
Courtesy of GENERAL MOTORS COMPANY	J-45053 Universal Clamp Press
Courtesy of GENERAL MOTORS COMPANY	J-8001 Dial Indicator Set
Courtesy of GENERAL MOTORS COMPANY	J-8107-4 Side Bearing Puller Pilot
