Installation Procedure

WARNING: This page is about a different car, the 2021 Cadillac XT6. However, it is still accessible from the selected car via links, so may be relevant.
GM4676988Courtesy of GENERAL MOTORS COMPANY
  1. Position the transmission mount strut bracket (2) to the transmission.
    CAUTION:

    Refer to Fastener Caution .

    CAUTION:

    Refer to Torque-to-Yield Fastener Caution .

  2. Install the 3 NEW transmission mount strut bracket bolts (1) and tighten to 100 N.m (74 lb ft) plus 45 to 60 degrees.
  3. Install the transmission mount strut. Transmission Mount Strut Replacement (All Wheel Drive) Transmission Mount Strut Replacement (Front Wheel Drive)
