Engine Accessories and Components
WARNING: This page is about a different variant/trim than selected.
| Callout | Component Name |
|---|---|
| 1 | Positive Crankcase Ventilation Tube - Tamper proof |
| 2 | Oil Filler Cap |
| 3 | Oil Filler Cap Seal |
| 4 | Oil Filler Cap Tube |
| 5 | Positive Crankcase Ventilation Tube |
| 6 | Fuel Feed Pipe |
| 7 | Fuel Feed Pipe Bolt |
| 8 | Engine Coolant Heater |
| 9 | Drive Belt Tensioner Bolt [2x] |
| 10 | Idler Belt Pulley |
| 11 | Drive Belt Tensioner |
| 12 | Idler Belt Pulley |
| 13 | Evaporative Emission Canister Purge Tube |
