Removal Procedure
WARNING: This page is about a different car, the 2022 Cadillac CT4. However, it is still accessible from the selected car via links, so may be relevant.
- Raise and support the vehicle. Lifting and Jacking the Vehicle
Exhaust Heat Shield Bolt-Left Front (1) - Remove
- Reposition the left front edge of exhaust intermediate underbody heat shield (2).
Exhaust Heat Shield Bolt (1) - Remove [5x]
- Exhaust Heat Shield Nut (2) - Remove [3x]
- Exhaust Front Underbody Heat Shield-Left Side (3) - Remove
