Knock Sensor Wiring Harness Replacement - Bank 2
WARNING: This page is about a different car, the 2022 Cadillac CT5. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Callouts in the following chart represent components shown in graphic above.
| Callout | Component Name |
|---|---|
| Preliminary Procedure Compressor Air Intake Turbocharger Replacement - Left Side |
|
| 2 | Knock Sensor Wiring Harness Procedure Disconnect the electrical connectors and remove from the 3 retainers. |
