Installation Procedure
WARNING: This page is about a different car, the 2022 Cadillac CT5. However, it is still accessible from the selected car via links, so may be relevant.
Water Pump Pulley (1) - Install
- CAUTION:
Refer to Component Fastener Tightening Caution .
Water Pump Pulley Bolt (1) - Install [4x] 10 N.m (89 lb in)
Accessory Drive Primary Belt (1) - Install - Accessory Drive Primary Belt Replacement
