Removal Procedure

  1. Disconnect the brake fluid level indicator switch electrical connector.
  2. GM2815580Courtesy of GENERAL MOTORS COMPANY

    Compress the locking tabs on the inboard side of the master cylinder reservoir and remove the brake fluid level indicator switch (1).
