Body Harness Routing Front of Passenger Compartment

GM4277879Courtesy of GENERAL MOTORS COMPANY
Items
1 J204 Body Harness
2 J205 Body Harness
3 J206 Body Harness
4 J207 Body Harness
5 J208 Body Harness
6 J209 Body Harness
7 J210 Body Harness
8 J211 Body Harness (V92)
9 W24 (V92)
10 J212 Body Harness
