Auxiliary Side Front Turn Signal Lamp Bulb Replacement (Left Side)

Fig 1: Auxiliary Side Front Turn Signal Lamp Bulb (Left Side)

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure  Remove Windshield Washer Solvent Container. Refer to Windshield Washer Solvent Container Replacement (Chevrolet/GMC)Windshield Washer Solvent Container Replacement (Cadillac)
1	Auxiliary Side Front Turn Signal Lamp Socket Procedure  Rotate the bulb socket counterclockwise and pull from the headlamp.
2	Auxiliary Side Front Turn Signal Lamp Bulb - Left Side Procedure  Pull the bulb straight out from the socket.
