1-2-3-4-5 Reverse Clutch Piston Installation

WARNING: This page is about a different car, the 2018 Chevrolet Suburban 3500 HD. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: 1-2-3-4-5 Reverse Clutch Piston
GM3785333Courtesy of GENERAL MOTORS COMPANY
1-2-3-4-5 Reverse Clutch Piston Installation

Callout Component Name
1 Output Shaft Bearing

Special Tools

  • DT-50897  Bearing Installer
  • GE-8092  Driver Handle

Equivalent regional tools: Special Tools .
2 1-2-3-4-5-Reverse Clutch Piston Dam Inner Seal
Procedure
Install a NEW seal. Do NOT reuse the old seal.
3 1-2-3-4-5-Reverse Clutch Piston Outer Seal
Procedure
Install a NEW seal. Do NOT reuse the old seal.
4 1-2-3-4-5-Reverse Clutch Piston
