Radio Speaker Amplifier Replacement

Fig 1: Radio Speaker Amplifier & Mounting Components

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure Remove the rear compartment side trim panel - right. Refer to Rear Compartment Side Trim Replacement - Right Side .
1	Fuel Pump Flow Control Module Bolt CAUTION: Refer to Fastener Caution .
2	Fuel Pump Flow Control Module Nuts (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
3	Fuel Pump Flow Control Module Bracket
4	Radio Speaker Amplifier Fasteners (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
5	Radio Speaker Amplifier Procedure Disconnect the electrical connectors. For programming and set up information, refer to Control Module References .
