B5RR Wheel Speed Sensor - Right Rear (J64+UGN)
|
|
Connector Part Information
- Harness Type: Right Rear Suspension
- OEM Connector: 23483158
- Service Connector: Service by Harness - See Part Catalog
- Description: 2-Way F
|
Terminal Part Information
| Terminal Type ID |
Terminated Lead |
Diagnostic Test Probe |
Terminal Removal Tool |
Service Terminal |
Tray Name |
Core Crimp |
Insulation Crimp |
| I |
Not Required |
Not Available |
No Tool Required |
Not Required |
Not Required |
Not Required |
Not Required |
| Pin |
Size |
Color |
Circuit |
Function |
Terminal Type ID |
Option |
| A |
0.1 |
WH |
7128 |
Wheel Speed Sensor Control Right Rear |
I |
- |
| B |
0.1 |
BK |
882 |
Wheel Speed Sensor Signal Right Rear |
I |
- |
