Radio Rear Side Door Speaker Replacement

Fig 1: Radio Rear Side Door Speaker
GM3630210Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
Preliminary Procedure
Remove the rear side door trim panel. Refer to Rear Side Door Trim Replacement (Chevrolet, GMC)Rear Side Door Trim Replacement (Cadillac) .
1 Radio Rear Side Door Speaker Fastener
CAUTION:

Refer to Fastener Caution .


Tighten
2.5 N.m (22 lb in)
2 Radio Rear Side Door Speaker

Procedure

  1. Release the clip retaining the speaker to the door frame.
  2. Disconnect the electrical connector.
  3. Unclip the wire harness from the speaker.
