KR74 Ignition Main Relay
| Callout | Component Name |
|---|---|
| 5199 | Run/Crank Relay Coil Control |
| 5199 L-GN/VT | 5199 L-GN/VT |
| CAV 17 | 17 |
| CONN X2 | X2 |
| CAV 15 | 15 |
| CONN X4 | X4 |
| CAV 86 | 86 |
| CAV 30 | 30 |
| CAV 85 | 85 |
| CAV 87 | 87 |
| 1150 | Ground |
| 1150 BK | 1150 BK |
| CAV 71 | 71 |
| CONN X1 | X1 |
| CAV 87A | 87A |
| G101 | G101 |
| F8DA | F8DA |
| F5UA | F5UA 5A |
| F13UA | F13UA 7.5 |
| F16UA | F16UA 10A |
| F17UA | F17UA 5A |
| F18UA | F18UA 5A |
| F19UA | F19UA 5A |
| F52UA | F52UA 5A |
| F53UA | F53UA 10A |
| F54UA | F54UA 5A |
| F57UA | F57UA 10A |
| K9 | K9 Body Control Module |
| KR73 | KR73 Ignition Main Relay |
| X50A | X50A Fuse Block - Underhood |
