Luggage Compartment Components (2 of 2)

Items
1. T3 Audio Amplifier T3 Audio Amplifier X1 T3 Audio Amplifier X2
2. K1 14V Power Module K1 14V Power Module X1 K1 14V Power Module X2 K1 14V Power Module X3 K1 14V Power Module X4 ()
3. A11 Radio A11 Radio X1 A11 Radio X2 A11 Radio X4 A11 Radio X5 A11 Radio X6 A11 Radio X9
4. K132 Pedestrian Alert Sound Control Module (H6P) K132 Pedestrian Alert Sound Control Module
5. K38 Chassis Control Module K38 Chassis Control Module
6. K114B Hybrid/EV Powertrain Control Module 2 K114B Hybrid/EV Powertrain Control Module 2 X1 K114B Hybrid/EV Powertrain Control Module 2 X2
7. K19 Suspension Control Module K19 Suspension Control Module ()
8. G38 14V Power Module Cooling Fan G38 14V Power Module Cooling Fan
9. C1 Battery
10. X50D Fuse Block - Battery X50D Fuse Block - Battery X1 X50D Fuse Block - Battery X2 X50D Fuse Block - Battery X3 X50D Fuse Block - Battery X4
11. B162R Vertical Body Acceleration Sensor - Rear B162R Vertical Body Acceleration Sensor - Rear
12. X53A Fuse Block - Rear Body X53A Fuse Block - Rear Body (Relay)X53A Fuse Block - Rear Body (Fuse)X53A Fuse Block - Rear Body (C Fuses)
13. X53A Fuse Block - Rear Body X53A Fuse Block - Rear Body (Relay)X53A Fuse Block - Rear Body (Fuse)X53A Fuse Block - Rear Body (C Fuses)

Fig 1: Luggage Compartment Components (2 of 2)

Courtesy of GENERAL MOTORS COMPANY
