Exhaust Muffler Insulator, Hanger, and Bracket Replacement

Exhaust Muffler Insulator, Hanger, and Bracket Replacement

Removal Procedure

1. Remove the muffler. Refer to Exhaust Muffler Replacement - Left Side (Service and Repair) or Exhaust Muffler Replacement - Right Side (Service and Repair).




2. Remove the muffler hanger bolt (1) and hanger.
3. Remove the hanger (2).

Installation Procedure




1. Install the hanger (2).

Caution: Refer to Fastener Caution (Fastener Caution).

2. Install the muffler hanger and bolt (1) and tighten the muffler hanger nuts to 16 Nm (12 lb ft).
3. Install the muffler. Refer to Exhaust Muffler Replacement - Left Side (Service and Repair) or Exhaust Muffler Replacement - Right Side (Service and Repair).
