Input and Output Speed Sensor Assembly Removal
Input and Output Speed Sensor Assembly Removal
| Callout | Component Name |
|---|---|
| 1 | Bolt M6 x 20 (Qty: 2) |
| 2 | Speed Sensor Electrical Connector Tip: Release the connector lock before disconnecting. |
| 3 | A/Trans Input and Output Speed Sensor Assembly |
| 4 | A/Trans Input and Output Speed Sensor Wiring Harness Clip (Qty: 2) Tip: Inspect the clips and replace if damaged. |
