35. Secondary Camshaft Drive Chain Removal - Left Side



Secondary Camshaft Drive Chain Removal - Left Side





Remove the left secondary camshaft drive chain from the left camshaft position actuators and the left camshaft intermediate drive chain idler sprocket.
