Removal Procedure

    Fig 1: View Of Hood Insulator And Push-In Retainers
    GM729783Courtesy of GENERAL MOTORS CORP.
  1. Open the hood.
  2. Remove the Front Hood Seal. Refer to Hood Front Seal Replacement .
  3. Remove the push-in retainers retaining the hood insulator to the hood.
  4. Remove the hood insulator from the hood.
