Installation Procedure

  1. Install the head up display switch to the knee bolster.
    Fig 1: Installing Head Up Display Switch To Knee Bolster
    G02099506Courtesy of GENERAL MOTORS CORP.
  2. Connect the head up display switch (1) electrical connector (2).
  3. Install the left knee bolster. Refer to KNEE BOLSTER REPLACEMENT - LEFT (WITHOUT UV2)  or KNEE BOLSTER REPLACEMENT - LEFT (UV2)  .
    Fig 2: Connecting Head Up Display Switch Electrical Connector
    G02099507Courtesy of GENERAL MOTORS CORP.
